Specifications |
|
Input Frequency Response |
0.15-1050MHz, 3dB |
|
Display Accuracy of
Central Frequency |
+/-200KHz (frequency sweep width +200KHz) |
|
Accuracy of Mark Frequency |
+/-0.1% (frequency sweep width +100KHz) |
|
Frequency Display Resolution |
100KHz (4½ bit LED display) |
|
Frequency Sweep Width |
0.1MHz/div-100KHz/div with 1, 2 and 5 step system
And 0Hz/div (0 frequency sweep) Accuracy: +/-10% (each range) |
|
Intermediate Frequency Bandwidth |
20KHz and 400KHz |
|
Video filter |
(When on) 4KHz |
|
Amplitude Range |
-107~+13dB |
|
Reference Level |
-27dB~+13dB (10dB for every step) +/-2dB |
|
Average Noise Level |
-97dB(20KHz intermediate frequency width) |
|
Display Range of CRT Screen |
80 dB(10dB/div) |
|
Display Range of Vertical Display |
+/-2dB (2 With attenuator) 250MHz signal |
|
Input Attenuator |
0-40dB (4x10dB step) error: +/-1dB/10dB |
|
Maximum Input Level |
+10dBm,+25V DC(Input attenuator set at 0dB)
+20dBm (input attenuator set at 40dB) |
|
Frequency Stability |
Over 150KHz/hour |
|
Input Jack Type |
BNC |
|
Input Impedance |
50¦¸ |
|
Power Supply |
220V/110V; +/-10%; 50Hz/60Hz |
|
Others |
|
|
DC Output |
+6V (for probe) |
|
AM Demodulation Output |
Load impedance ¡Ý16¦¸ |
