Specifications

Input voltage Range

Voltage: 1mV to 10V(resolution:1mv) Max. display 3999 Extended to 300v using 40db voltage divide (optional)   Full scale in 4 ranges are:40mv,400mv,4v,10v

Frequency Range

100HZ~1000MHZ(10HZ~1000MHZ when using low frequency probe)

Voltage Error

> 40mv ±1%±10digits
   > 10mv ±1.5%±20digits
> 10mv ±2%±20digits

Voltage Measuring Range

-20~+40dBm (0dBm-0.224v. 50 Ω load

Frequency Response Error

100kHz~50MHZ: ±3% //1KHZ~600MHZ: ±8%// 100HZ~1000MHZ: ±10%//10HZ~1000MHZ: ±15%

Operation Error

> 40mv ±2%±10digits
>1 0mv ±3%±20digits
> 10mv ±5%±40digits

Input Impedance

≤15KΩ (at range 40mv) Capacitance: <2.5pF

Power Supply

220V/110V ±10%: 50Hz/60Hz

Dimension

210(w)x140(h)x245(d)mm

Weight

4Kg
