Product Specification:
Display: Max. display 1999
Inductance Measure: 1uH~20H
Capacitance Measure: 1pF~2000uF
Zero Adjust: Capacitance under 20nF is manual ministrant zero adjust.
Sampling Rate: 0~5s
Working Temperature: 0~40¡æ
Relative Humidity: Less than 80%
Dimension: 185x93x35mm
Weight: 290g
Power Supply: 9V battery
Capacitance:
|
Range |
Resolution |
Accuracy |
|
2nF |
1pF |
¡À(2.0%+5)
|
|
20nF |
10pF |
|
200nF |
100pF |
|
2UF |
1000pF |
|
20UF |
0.01UF |
|
2000UF |
1UF |
¡À(5.0%+5) |
Inductance
|
Range |
Resolution |
Accuracy |
|
2mH |
1uH |
¡À(2.0%+5) |
|
20mH |
10uH |
|
200mH |
100uH |
|
2H |
1mH |
|
20H |
10mH |
¡À(5.0%+5) | |
